Series E – PML Tie Rod Style 2500 PSI
Product Details
Tube: ST 52.3 – Precision Honed for maximum seal performance and long life
Rod: Ground / Polished & Hard Chrome Plated for extended cylinder life
Threaded Rod Clevis: 80-55-06 Ductile for increased strength and durability
- Cylinders come with pins and clips
- 2500 PSI models come standard with NPT ports
- Economical design for light to medium duty applications
- Flexible port locations allow for ease of mounting
Additional Specifications
| BORE | 2.00 | 2.50 | 3.00 | 3.50 | 4.00 | 5.00 |
|---|---|---|---|---|---|---|
| A ASAE-8 | 12.25 | 12.25 | 12.25 | 12.25 | 12.25 | 12.25 |
| A ASAE-16 | 15.5 | 15.5 | 15.5 | 15.5 | 15.5 | 15.5 |
| A | 10.25 | 10.25 | 10.25 | 10.25 | 10.25 | 12.25 |
| B | 0.19 | 0.19 | 0.19 | 0.19 | 0.19 | 1.25 |
| C | 3/8″NPT | 3/8″NPT | 1/2″NPT | 1/2″NPT | 1/2″NPT | 1/2″NPT |
| E | 2.50 | 2.50 | 2.50 | 2.50 | 2.62 | 2.88 |
| G | 2.50 | 2.50 | 2.72 | 2.72 | 2.72 | 2.95 |
| H,I | 1.16 | 1.16 | 1.16 | 1.16 | 1.16 | 1.20 |
| J | 2.13 | 2.13 | 2.13 | 2.13 | 2.13 | 1.87 |
| M | 2.00 | 2.00 | 2.00 | 2.00 | 2.00 | 2.12 |
| P | 0.35 | 0.35 | 0.43 | 0.43 | 0.50 | 0.72 |
| Q | 1 1/8-12 UNF | 1 1/8-12 UNF | 1 1/4-12 UNF | 1 1/4-12 UNF | 1 1/4-12 UNF | 1 1/2-12 UNF |
| R | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.25 |
| S | 2.00 | 2.00 | 2.13 | 2.25 | 2.25 | 2.76 |
| T | 2.00 | 2.00 | 2.25 | 2.25 | 2.25 | 2.75 |
