Extreme Duty: 2.0 to 5.0 GPM Chemical Resistant Pumps
Product Details
Pump Type: Demand
Flow: Up to 5.4 GPM
Pressure: Up to 60 PSI
Valves: Viton
Diaphragm: Geolast
Ports: 3/8” FNPT, ¾” Quick Attach, ½” FNPT
Power: 12V – Wire Leads with 2-pin molded connector
Weight: 6, 8 lbs.
Packaging: Bulk Box, Retail Box
Shipping: 6 per carton, single
• Extreme Duty components built to withstand oil and diesel blends
• Resilient Geolast Diaphragm for longer life when spraying harsh chemicals
• 100% Factory tested
• High Torque Motor for superior flow at pressure
• Self-Priming
• Can be run dry
Additional Specifications
2.0 GPM Demand
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 1.7 | 4.5 |
| 10 | 1.7 | 4.5 |
| 20 | 1.6 | 5.2 |
| 30 | 1.55 | 5.9 |
| 40 | 1.5 | 6.7 |
| 50 | 1.45 | 8 |
2.2 GPM Demand
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 2.2 | 4.5 |
| 10 | 2.2 | 4.7 |
| 20 | 2.1 | 6.1 |
| 60 | 1.9 | 6.9 |
| 40 | 1.8 | 7.2 |
| 50 | 1.65 | 8.1 |
5.0 GPM Demand
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 5.4 | 8.2 |
| 10 | 4.6 | 10.4 |
| 20 | 4.1 | 12.5 |
| 30 | 3.7 | 15.1 |
| 40 | 3.2 | 16.3 |
| 50 | 2.8 | 17.1 |
Extreme Duty Bypass-Demand Diaphragm Pump Product Lising
| Item # | GPM | Pump Type | PSI | Valves | Diaphragm | Ports | Wire Leads |
|---|---|---|---|---|---|---|---|
| 7812ED-201-SB | 2 | Demand | 60 | Viton | Geolast | 3/8″ FNPT | • |
| 7822FSED-201-SB | 2.2 | Demand | 60 | Viton | Geolast | 3/4″ QA | • |
| 5850ED-201C-SB | 5 | Demand | 45 | Viton | Geolast | 1/2″ FNPT | • |
