FB2 Series: 7.0 GPM Pumps
Product Details
Pump Type: Demand
Flow: 2.2 GPM
Pressure: 60 PSI
Valves: Viton
Diaphragm: SantoprenePump Type: Bypass, Demand
Flow: Up to 7 GPM
Pressure: Up to 100 PSI
Valves: Viton
Diaphragm: Santoprene
Ports: ½” FNPT, ¾” Quick Attach
Power: 12V – Wire Leads with 2-pin molded connector
Weight: 8 lbs
Packaging: Bulk Box, Retail Box
Shipping: 6 per carton, single
- 100% Factory tested
- NSF Approved
- High Torque Motor for superior flow at pressure
- Self-Priming
- Can be run dry
Additional Specifications
FB2 7.0 GPM Bypass
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 7.2 | 12.3 |
| 10 | 6.7 | 13.9 |
| 20 | 6.3 | 16.4 |
| 40 | 5.1 | 19.1 |
| 60 | 4.5 | 22.5 |
| 80 | 3.6 | 25.3 |
| 90 | 2.8 | 27.1 |
FB2 7.0 GPM Demand
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 7.2 | 12.3 |
| 10 | 6.7 | 13.9 |
| 20 | 6.3 | 16.4 |
| 40 | 5.5 | 19.1 |
| 60 | 4.8 | 22.5 |
| 80 | 4.5 | 25.3 |
| 90 | 4.1 | 27.1 |
