FB3 Series: Heavy Duty 7.0 GPM Pumps
Product Details
Pump Type: Bypass, Demand
Flow: Up to 7 GPM
Pressure: Up to 100 PSI
Valves: Santoprene
Diaphragm: Santoprene
Ports: ½” FNPT, ¾” Quick Attach
Power: 12V – Wire Leads with 2-pin molded connector
Weight: 8 lbs
Packaging: Bulk Box, Retail Box
Shipping: 6 per carton, single
- 100% Factory tested
- Heavy Duty Reinforced Diaphragm for longer life
- High Torque Motor for superior flow at pressure
- Self-Priming
- Can be run dry
Additional Specifications
FB3 7.0 GPM Bypass
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 7.2 | 13 |
| 10 | 6.6 | 15.1 |
| 20 | 6.2 | 17.4 |
| 40 | 5.4 | 20.1 |
| 60 | 4.3 | 23.3 |
| 80 | 3.4 | 26.7 |
| 90 | 2.7 | 29.2 |
FB3 7.0 GPM Bypass
| PSI | GPM | AMPS |
|---|---|---|
| 0 | 7.2 | 13 |
| 10 | 6.6 | 15.1 |
| 20 | 6.2 | 17.4 |
| 40 | 5.4 | 20.1 |
| 60 | 4.6 | 23.3 |
| 80 | 4.1 | 26.7 |
| 90 | 3.8 | 29.2 |
